olivals main.png


THE TRUSTED SOLUTION
FOR VALVE MAINTENANCE



ON-LINE VALVE LUBRICATION & SEALING (OLIVALS™)

OLIVALS™ products are manufactured in the only National Lubricants and Grease Institute, USA (NLGI) certified grease blending plant in the USA.

The OLIVALS™ range of high quality valve cleaners (flush), lubricants and sealants have been proven effective throughout the years. They have been specially formulated to clean, lubricate and seal passing or leaking valves from many years of field experience.



OLIVALS™ PRODUCTS

Specialised Products for Valve Preventive and Emergency Sealing Services

OLIVALS™ VALVE FLUSH

OLIVALS™ VF - Liquid Valve Flush

  • A unique combination of solvent for valve cleaning. Safely removes oxidation (rust & scale) & dissolves solidified hydrocarbon deposits.

  • Corrosion inhibiting film to stop oxidation.

  • Non-corrosive and will not harm any valve metal components such as springs, valve seat and seals.

  • Non Fammable, non-health hazard.


OLIVALS™ VALVE LUBRICANT

OLIVALS™ VL - Fully Synthetic

  • Minimize internal friction of moving parts. Adheres to metal - protects against rust & corrosion

  • Anti-Hardening - will not block the lubrication ports, will not solidify on valve seats.

  • Contains no clay or bentonite or soaps as filler materials. Resistant to wash out.

  • Non-flammable, non-health hazard.

  • Maximum temperature range 600℉

VL pic.jpg

OLIVALS™ VALVE REPAIR SEALANT

OLIVALS™ VRS - Fully Synthetic

  • Synthetic grease sealant for high pressure and high-temperature valve operation

  • Formulated with resins, graphite, and Liquillon.

  • Service temperature -12℃ up to >532℃

  • Maximum resistance to H2S and hydrocarbon fluids. Corrosion-resistant, waterproof. Excellent sealing capabilities.



OLIVALS™ GATE VALVE SEALANT 2

OLIVALS™ GVS2 - Fully Synthetic

  • Improved synthetic gate valve lubricant and emergency sealant.

  • Formulated with Liquillon and silica amorphous.

  • Excellent lubrication and sealing capability for valves exposed to carbon dioxide.

  • Service temperature -45℃ up to >260℃

  • NLGI Grade 2-3

  • Excellent resistance to carbon dioxide, insoluble to water, brine, and hydrochloric acid.

  • Non-melting and non-hardening.

  • Contains no soap and zero bentonites.



OLIVALS™ EQUIPMENT

Customised equipment to optimise the effectiveness of OLIVALS™ products safely.


OLIVALS™ 751

Valve Master Pump Lubricant & Sealant

Operating air pressure range  : 30-200psi

Air inlet  : ½” NPTF

Operating temperature  : -34C + 93C

Max delivery pressure  : 15,000psi

Max output @ 75 cpm  : 4500 cc per min / 1lb per 16 strokes

  • Outlet hydraulic hose c/w fittings & adapter with 15,000 psi operating pressure rating

  • Inlet hydraulic hose c/w fittings & adapter with 300 psi operating pressure rating.


OLIVALS™ FM-II

OLIVALS™ FM-II High Pressure Valve Flush Pump

Operating air pressure range  : 30-200psi

Air inlet  : ½” BSP

Operating temperature  : -34C + 93C

Tank capacity  : 6.5 L

Max delivery pressure  : 15,000 psi@145psi.

  • Outlet hydraulic hose c/w fittings & adapter with 15,000 operating pressure rating

  • Inlet hydraulic hose c/w fittings & adapter with 300 psi operating pressure rating.



OLIVALS™ ACCESSORIES

OLIVALS also manufacture and supply its own brand fittings with 10k pressure (minimum) with various sizes and with high range of quality material

Inconel, 316 SS, K Monel, chrome alloy.

  • Vent Cap and Button Head type fitting

  • Leak Lock Adapter

  • Safe Vent Coupler

  • Pressure Release Tools (PRT)

  • Range Size – ⅜”, ¼”, ½”, ¾”, 1”, 1½”


accessories 1.jpg
accessories 2.jpg

OLIVALS™ MAINTENANCE PROGRAMS

We offer two maintenance service programs and they are suitable for ball, pliug and gate valves including X-mas trees with seat injection fittings

Reactive Maintenance Services

Flushing & sealing ad-hoc. On-call to service any jammed and passing valves

Preventive Maintenance Services

Lubricating and sealing (periodic scheduled maintenance). Schedule periodical flushing & lubricating services to fit customer's requirements for:

  • Valves on the pipeline network

  • Valves on the process line

  • Wellheads in the production field

  • X-mas trees for wellheads



PREVENTIVE MAINTENANCE PROGRAM

Long Term Solution

This program develops a comprehensive valves database that enables the operator to manage any type of service or maintenance required. This program minimizes unplanned downtime due to valve failure and increases productivity.


Valve inventory will be reduced thus less holding cost and this program prolongs valves' service life up to 50-60%. It could also reduce overall maintenance costs.
